Number: 3930 |
|
| |
| Category: |
Collating machine - Calendar |
|
| Manufacturer: |
Theisen & Bonitz |
| Model: |
tb sprint B 317 VP |
| Built: |
1998 |
| Size: |
35 x 50 cm |
| Status: |
In production |
| Test: |
By prior appointment agreement possible |
| Location: |
Germany |
| Availability: |
n.V. |
| | |
| Machine: | Calendar Collating-machine |
| Manufacturer: | - Theisen & Bonitz |
| Built: | - 1998, - General overhaul by T & B in September 2020 |
| Type: | - tb sprint |
| Model: | - tb sprint B 317 VP |
| Stations: | - 17 stations |
| - Hand feeding station right |
| Format: | - max. 35,0 x 50,0 cm |
| - min. 10,0 x 10,0 cm |
| Stack height: | - max. 30 cm |
| Material thickness: | - 18 - 1.000 g/qm |
| Control: | - SPS - program control |
| Controls: | - Miss sheet control at each station |
| - Electromechanical double sheet control at the delivery |
| - Paper jam control for transport table |
| Conveyor table: | - Shed sliding table for cross transport |
| - Transport table illumination |
| Counter: | - Total- and pre-selection batch counter |
| Equipment: | - Automatic approach and departure of the stations |
| - Missed sheet repeat |
| - Vacuum connection for 303/304 QSM |
| - Electrical connection for 303/304 and 345 N |
| Delivery: | - Delivery shaker for normal and crossed delivery |
| Condition: | How it stands and goes |
| - Very good, technically overhauled by Theisen & Bonitz in 2020 |
| |
| Speed: | max. 2.600 sheets/h |
| Digital speed display in AT / h |
| Length: | 8.200 mm |
| Width: | 1.420 mm |
| Height: | 1.650 mm |
| Weight: | 2.800 kg |
| Air supply: | Pressure-vacuum pumps in a soundproofed housing |
| Power supply: | This machine is connected to 400 V, 50 / 60 Hz. |
| Important: | Connection requirements of any power utility note! |
| CE mark: | The machine bears the CE mark |
| |
| Price: |
On request |
| (exclude VAT) |
